Applications
Acrylic fiberglass sleeving is made of non-alkali fiberglass with acrylic resin coated ,it has reliable heat resistance and excellent dielectric ,it can be used as wiring insulation for motors .electricalinstruments Etc. It is used in electromechanical industry(motors .transformers,generators..)all
class F insulation.
Features
-Temperature class: F
-Continuous working temperature :from -40°C to+155°C -Dielectric strength:2.5KV,4KV and 7KV-Halogen free .good mechanical resistance
-Good compatibility with class F impregnation varnishes -Watertight .very flexible
Colour&Package
-Diameter:0.5mm to 25mm
-Colour:yellow,black .natural Etc.
Standard
EN60684(10-2003)

Dimensions

Inside diameter		The minimum wall thickness
Range	Tolerance	A grade	B grade
0.5-2.5mm	+0.25-0.00mm	0.38mm	0.20mm
3.0-4.5mm	+0.30-0.00mm	0.45mm	0.23mm
5.0-6.0mm	+0.40-0.00mm	0.45mm	0.28mm
7.0-9.0mm	+0.55-0.00mm	0.50mm	0.32mm
10.0-14.0mm	+0.75-0.00mm	0.60mm	0.40mm
15.0-25.0mm	+0.85-0.00mm	0.64mm	0.43mm

Technology Index-Characteristics      Off-self time: 30seconds

Specification

Continuous Operating Temperature	Flame Retardance	Insulating	Oil Endurance
-40℃+155℃	Non-Flame Retardance	Insulating	Oil Endurance ( non-water endurance)
