Applications
Perfect for numerous electronic, automotive and consumer goods. Suitable for electrical insulation,
protection of components, strain relief, Cable bounding, identification.

Features
Specially designed formula approved by UL. Flexible and flame retardant. Free from toxic heavy metal
and harmful substances such as PBB's, PBBO's, PBBE's. Offering low Shrinking temperature.

Various
Operating temperature : -55°C to +135°C
Minimum shrink temperature: 80°C
Minimum fully recovery temperature: 100°C
Approvals: UL 224 125°C VW-1 600 V
Cadmium content < 5 ppm. RoHs compliant
Standard colors: Black, red, blue, yellow, green, white. Other colors available on request.
Shrink ratio: 2:1 (3:1 and 4:1 available.)

Technical Data

Property	Test Method	Typical Data
Operating temperature	UL 224	-55°C to+ 135°℃
Tensile strength	ASTM D 2671	>14 MPa
Elongation at break	ASTM D 2671	400%
Longitudinal shrinkage	UL 224	0±5%
Eccentricity	ASTM D 2671	<30%
Flammability	VW-1	Pass
Dielectric strength	IEC 243	>20 KV/mm
Yolume resistance	IEC 93	1014Ω.cm
Copper stability	UL 224	Pass
Heat aging / Tensile strength / Ultimate elongation	158°℃/168h	Unaged/>12 MPa/>350%

Dimensions/Shrink ratio 2:1

Size	As Supplied(mm)		After Recovery (mm)		Standard length m/spool
Inch. (D)	Inside Diameter Min. (D)	Wall Thickness Nominal. (T)	Inside Diameter Max. (d)	Wall Thickness nominal. (t)
3/64	1.2	0.18	0.65	0.30	200
1/16	1.6	0.18	0.85	0.33	200
3/32	2.4	0.25	1.2	0.36	200
1/8	3.2	0.25	1.6	0.44	200
3/16	4.8	0.25	2.4	0.55	200
1/4	6.4	0.25	3.2	0.55	200
3/8	9.5	0.30	4.8	0.55	100
1/2	12.7	0.35	6.4	0.65	100
5/8	16	0.35	8	0.69	100
3/4	19.1	0.40	9.5	0.89	100
1	25.4	0.45	12.7	0.90	50
11/4	32	0.45	16	0.90	50
11/2	38.1	0.50	19.1	1.00	50
2	50.8	0.50	25.4	1.00	25
3	76.2	0.55	38.1	1.20	25
4	100	0.55	50.8	1.30	25
5	120	0.55	63	1.40	25
6	150	0.55	75	1.40	25
7	180	0.55	90	1.40	25

Dimensions/Shrink ratio 3:1

Size	As Supplied(mm)		After Recovery(mm)		Standard length m/spool
DM-T135 3X inch. (D)	Inside Diameter Min. (D)	Wall Thickness Nominal.(T)	Inside Diameter Max. (d)	Wall Thickness Nominal.(t)
1/16	1.5/0.5	0.15	0.5	0.45	200
1/8	3/1	0.18	1.0	0.55	200
3/16	4.5/1.5	0.20	1.5	0.60	100
1/4	6/2	0.22	2	0.65	100
3/8	9/3	0.30	3	0.75	50
1/2	12/4	0.35	4	0.80	50
5/8	15/5	0.35	5	0.85	50
3/4	18/6	0.40	6	0.89	50
1	24/8	0.45	8	1.00	25
11/4	30/10	0.45	10	1.15	25
11/2	39/13	0.50	13	1.25	25
2	50/16	0.75	16	2.3	1
21/2	60/20	0.80	20	2.4	1
3	70/23	0.85	23	2.4	1
4	100/33	0.85	33	2.4	1

*Spools as standards. 1 m. or 1,22 m. sticks, special spool lengths or cut pieces available on request.
Special sizes (up to 7 inches) and other special features available on request
