135度,耐液级标识热缩管

更新:2017/6/16 17:05:16点击:
  • 产品品牌
  • 产品型号D-marking135F
  • 在线订购
产品介绍
Applications
Special designed to meet the requirements of high performance
identification of wire and cables where exposure to organic fluids,
especially oils, is required. It is made of superior fluid resistant
flame retardant polyolefin with excellent electrical, physical,
chemical and printing properties. It can be easily printed by
marker printers with permanent identification widely used in
aerospace, military, railway, construction industry, etc.
Features
Shrink ratio 3:1
Fluids resistant.
Meet the requirements of aerospace and railway use.
Excellent printing property, permanent identification to meet
SAE AS81531.
Excellent electrical, physical, chemical and printing properties.
RoHS and REACH compliant.
Operating temperature range:
Operating temperature: -55℃ ~ 135℃
Minimum shrink temperature: 80℃
Minimum fully recovery temperature: 120℃
Approvals:
SAE AMS-DTL-23053/5
UL224 125℃ 600V
SAE AS 81531,MIL-STD-202



Notes:
Other sizes are available upon request.
Color:
Standard color: White or yellow
Other colors are available upon request.
